Evo 1-3 Td05/06 - Turbo Manifold
or 6 weekly payments from $187.83 learn more
After years of development of our merge collector from extensive dyno time and feedback from the top tuners in the country, we have found the perfect balance of boost control and flow. With minimal back pressure where the manifold meets the turbo, you can be sure that you're getting the best flow possible from your turbo manifold. FLOW = POWER.
For information on material types please follow the link: FAQ
NOTE = Will not fit vr4, because of the front cross-member that the vr4 chassis has
- Fitment= Td05/06 turbos - This position twists the turbo away from the block allowing for the td06 compressor cover to clear the water pipe at front of engine
- Features 4-1 merge collector
- 12mm CNC machined flanges
- Runner size = 35mm inside diameter
5 year no crack warranty
10 year no crack warranty if fitted by us in store
Manifold Manufacture Times
Our manifolds are made to order, manufacturing times vary depending on the time of year & our current work load.
Please email or message us if you want to know exact time frames
