Steampipe Elbow 90 - 1 1/4"
Sinco D.I.Y.
$5.80
or 4 interest free payments of $1.45 withlearn more
or 6 weekly payments from $0.97 learn more
Radius
Quantity
Our range of steampipe bends and straight are sandblasted to a raw finish so you can weld them straight out of the box. From manufactures generally the steampipe elbows will have a black or clear paint on them to ensure they will not rust over time when stored, the fumes this paint creates when welding is very harmful if inhaled.
- For the use of manufacturing turbo manifolds
- Steam pipe elbow - Sch. 40 (3.7mm thick)
- 35mm Inside diameter
- Short radius = 32mm CLR (What is CLR?)
- Long radius = 49mm CLR (What is CLR?)
Quick Reference:
1 1/4" steamtube bends =
Inside Diameter - 35mm
Outside Diameter - 42mm
1 1/2" steamtube bends =
Inside Diameter - 41mm
Outside Diameter - 48mm
2" steamtube bends =
Inside Diameter - 52mm
Outside Diameter - 60mm
